D2D160-CE02-11 ebmpapst Centrifugal Fan M2D074-LA 230VAC 700W 1.9A 50/60Hz 2700 Rpm

1.Overview of the D2D160-CE02-11 ebmpapst

The D2D160-CE02-11 is a backward-curved centrifugal fan that integrates AC technology, featuring a compact structure and high energy efficiency. It is specifically designed for effectively cooling high-power electrical equipment such as ABB frequency converters and inverter modules, ensuring that internal power components (such as IGBTs) operate at safe temperatures, significantly improving the overall reliability and lifespan of the equipment.

The fan uses galvanized steel sheet as the main material for the impeller and casing, giving the product excellent mechanical strength and corrosion resistance, enabling it to adapt to various harsh industrial environments.

Highly Efficient and Powerful Heat Dissipation
With an airflow of up to 1205 m³/h and an input power of 700 W, this fan generates powerful airflow sufficient to handle the high heat generated by high-power frequency converters and inverter modules, effectively preventing equipment overheating.

Rugged and Durable Industrial-Grade Design
The entire fan is constructed from galvanized steel, ensuring long-term stability and corrosion resistance even in harsh environments. The use of ball bearings guarantees its mechanical lifespan and reliability under long-term high-speed operation.

Comprehensive Safety Protection Mechanism
The fan integrates a thermal overload protector (TOP), which automatically cuts off the power supply when the motor overheats abnormally, providing critical protection for core drive components. Class F insulation allows the motor to operate safely at higher temperatures.

Wide Environmental Adaptability
Supporting a wide operating temperature range of -25°C to +90°C, and with the motor capable of stable operation in any installation position, it can adapt to a variety of complex industrial applications.

2.Core Features:

Model: D2D160-CE02-11
Fan Type: Double-inlet forward centrifugal fan (without volute)
Impeller Diameter: 160 mm
Rated Voltage: 230 V AC (single-phase) or 3～400 V AC (three-phase) 50 Hz
Rated Power: 700 W (50 Hz) / 1055 W (60 Hz)
Rated Current: 1.9 A (230 V) / 3.0 A (400 V)
Rated Speed: 2700 rpm (50 Hz) → 3000 rpm (60 Hz)
Maximum Airflow: 1205 m³/h
Maximum Static Pressure: 450 Pa
Noise Level: 64 dB(A) (free field, 1 m)
Operating Temperature: –40 … +70 °C (continuous operation)
Bearing System: Maintenance-free ball bearings, L10; Life ≥ 30,000 h (40 °C)
Insulation/Protection: Class F insulation, IP00 (for internal use, external mesh cover required)
Material: Galvanized steel impeller & housing, black painted finish
Installation: Wall-mounted in any position, 4 × Ø7 mm mounting holes, 190 × 190 mm
Weight: ≈ 13 kg
Certifications: CE, UL, CCC, CSA, compliant with EN 60335-1

Core Functions

High Airflow and High Air Pressure: 1205 m³/h + 450 Pa, directly penetrating the IGBT high-density heat sink, reducing temperature rise by 10-15 K.

Wide Voltage Global Compatibility: 230 V single-phase / 400 V three-phase options available at the factory, 50/60 Hz universal, reducing inventory SKUs.

Heavy-Duty Design: 700 W high-power asynchronous motor, F-class insulation, built-in thermal protection, can operate continuously at -40…+70 °C, suitable for high-altitude, humid, and dusty environments.

Long Lifespan and Maintenance-Free: Ball bearings, ≥30,000 h L10 lifespan, daily operation only requires wiping the air intake screen, no lubrication required.

Low Noise Operation: 2700 rpm dynamic balance G2.5, overall unit noise level 64 dB(A), improving cabinet sound quality.

Ready to use immediately: 160 mm standard flange, 100% compatible with the screw positions of the entire ABB ACS800-104 series power units, the whole unit weighs 13 kg and can be directly wall-mounted without the need for a transition plate.

Typical Applications

• Cooling for ABB ACS800/ACS880/ACS580 power units

• High-power servo drives, photovoltaic inverters, wind power converters

• UPS, battery energy storage systems, data center in-row air conditioning

• High-pressure air supply for industrial dust removal and purification equipment
